Windsor Heritage Street Lighting Product image 2000x1572px Alt4

Our signature lantern



Handcrafted in copper using traditional methods, Windsor combines timeless design
and award-winning optical performance to deliver a superior quality of light.

Product features

Copper construction

For more than 40 years, we have been handcrafting an extensive range of copper lanterns. As well as being attractive, copper is a tough and corrosion-resistant material offering longevity.

Mounting options

Windsor Avenue, Street and Boulevard are supplied with a Ø76mm frog mounting as standard. Windsor Street is also available with an optional cast base.

Suggested column / bracket options

Check out our range of durable yet decorative columns, brackets, and wall brackets that seamlessly fit into any application. For help to pick the solution, get in touch with our team of experts.

Installation and maintenance

Frog and cast bases have external connector blocks for ease of installation. Toolless maintenance via hinged, sealed canopy with retaining stay and slide latches.

Products in this range

Windsor Avenue



Lumen Output 950 - 9,950lm
 Power 5 - 80W
 Weight 8.3kg
 Windage 0.031m2

Windsor Street



Lumen Output 950 - 9,950lm
 Power 5 - 80W
 Weight 10.3kg
 Windage 0.40m2

Windsor Boulevard



Lumen Output 900 - 21,000lm
 Power 11 - 187W
 Weight 12.3kg
 Windage 0.54m2
dww website banner dark sky windsor ds 9

Windsor DS

DarkSky Approved lighting designed to combat
light pollution and protect the night sky.



View Windsor DS

Heritage LED light engines

Designed to fit effortlessly within the majority of our exterior lighting luminaires, the LED Light Engine is available in new luminaires or as a retrofit option.

Performance LED

Best for applications where performance and flexibility are key

Performance CoB

Best for applications which require a single, high performance light source

Comfort CoB®

Best for applications where a more traditional appearance is needed

Gas effect

Best for applications that demand the ultimate authentic heritage aesthetic

Standard colours

RAL 9005 Fine textured black colour swatch 548x548px

RAL 9005

Black

RAL 7016 Anthracite grey colour swatch 548x548px

RAL 7016

Anthracite grey

RAL 7037 Dusty grey colour swatch 548x548px

RAL 7037

Dusty grey

RAL 5003 Sapphire blue colour swatch 548x548px

RAL 5003

Sapphire blue

RAL 6005 Light moss green colour swatch 548x548px

RAL 6005

Light moss green

RAL 3005 Wine red colour swatch 548x548px

RAL 3005

Wine red

natural copper colour swatch 548x548px2

Copper

Natural finish

polished copper colour swatch 548x548px

Copper

Polished finish

To personalise your scheme, other RAL colours available on request.

Detailed Specification

Product specification

Electrical Class:
I (II on request)
IP rating:
IP65
IK rating:
IK08
Certifications:
UKCA, CE, ENEC
Mounting Height (m):
3 - 10 m
Applications:
Public realm
Roads
Footpaths
Car parks
Rail

Lighting

Light source:
Performance LED, Performance CoB, Comfort CoB
Lumen Range (lumens):
980 - 12,540 lm
Power Range:
6 - 105 W
LED qty:
8 - 32
Distribution:
Performance LED: 14 Diamond+ Optics
Performance CoB: 4 Optics
Comfort CoB: 1 Optic
Colour Temperature (CCT):
2700K
3000K
4000K
Colour rendering (CRI):
70Ra / 80Ra (light source dependant)
L90 Lifetime Estimate:
>100,000hrs

Power and control

Voltage:
220 - 240V
Drive Current Range:
250mA - 1050mA (in 50mA increments)
Controls:
Miniature photocell
Part-night switching
Pre-programmed dimming
Zhaga Book 18 socket
Integral CMS
Sensor ready
Surge protection:
10kV
Driver:
Fully programmable

Mechanical and installation

Materials:
Body: Copper
Glazing: Clear polycarbonate
Seals: Silicone
Finish:
Natural copper
Polished and lacquered copper
Polyester powder coat
Product colours:
RAL 9005 Black
RAL 7016 Anthracite grey
RAL 7037 Dusty grey
RAL 5003 Sapphire blue
RAL 6005 Light moss green
RAL 3005 Wine red
Natural copper finish
Polished and lacquered copper finish
Other RAL colours on request
Mounting:
Post top: Ø76mm
Wall bracket

Dimensions

Windsor Avenue product dimension drawing W573px
Dimensions (mm):
  • A 745
  • Ø B 390
  • Ø C 76
  • D 115
Weight (kg):
8.3
Windage (m2):
0.31
Windsor Street product dimension drawing W573px3
Dimensions (mm):
  • A 833
  • Ø B 440
  • Ø C 76
  • D 188
Weight (kg):
10.3
Windage (m2):
0.40
Windsor Street product dimension drawing W573px3
Dimensions (mm):
  • A 1005
  • Ø B 495
  • Ø C 76
  • D 188
Weight (kg):
12.3
Windage (m2):
0.54
