Simple decorative illuminated bollard, from Focus by DW Windsor
Sticks' simple cylindrical form is completed with a single or double light aperture in opalised acrylate, designed by Schmidt Hammer Lassen Design. During daylight, Sticks is simply part of the environment; at night, light predominates and the surroundings step into character.
- Sticks is available in two sizes, 900mm and 3000mm
- Asymmetric and symmetric distributions are available depending on number of light apertures
- Mounting is achieved via flange plate or root
Request a quote
Request a quote
Product Selector
Dimensions (mm)
Options in this range
| Name | Light source | Distribution | Dimensions (mm) | |
|---|---|---|---|---|
| Sticks 900 Single | Citizen CoB Array | Asymmetric | Height: 900 | |
| Sticks 900 Double | Citizen CoB Array | Symmetric | Height: 900 | |
| Sticks 3000 Double | 2 x 14W T8 LED tube | Symmetric | Height: 3000 | |
| Sticks 3000 Single | 1 x 14W T8 LED tube | Asymmetric | Height: 3000 |
Detailed Specification
Product specification
Electrical Class:
I (II on request)
IP rating:
IP55
IK rating:
IK08
Certifications:
CE
Lighting
LED qty:
1-2
Power and control
Controls:
Remote switch
Mechanical and installation
Materials:
Body: Fabricated aluminium
Glazing: Opal-white
impact-resistant acrylate
Glazing: Opal-white
impact-resistant acrylate
Finish:
Polyester powder coat
Product colours:
SW302G Graphite grey
MW300D Silver grey
SN351F Black (Noir 900 Sablé)
RAL 9005 Black
YX355F Corten brown (Mars 2525)
Other RAL colours on request
MW300D Silver grey
SN351F Black (Noir 900 Sablé)
RAL 9005 Black
YX355F Corten brown (Mars 2525)
Other RAL colours on request
Mounting:
Root mounted
Flange plate
Flange plate
Dimensions
Dimensions (mm):
- A 900
- B 500
- Ø C 120
- D 600
- Ø E 195
Weight (kg):
15.5
15.5
Dimensions (mm):
- A 3000
- B 870
- Ø C 120
- D 650
- Ø E 195
Weight (kg):
30
30
